ITL – 700×300 LMGTV SPM Large Size Double Column Horizontal Band Saw Machine

by ITL
Original price Rs. 0.00 - Original price Rs. 0.00
Original price
Rs. 0.00
Rs. 0.00 - Rs. 0.00
Current price Rs. 0.00

“INDTOOLS” High Speed Double Column with Linear Motion Guide (LMG) Semi Automatic Horizontal Bandsaw Machine "Cutting head up-down movement guided in Vertical pair of imported linear Motion bearing for
jerk free movement."
"Infinitely variable pressure controlled cutting feed & upward return rapid movement by hydraulic
Quick approach of cutting head upto the bar before cutting starts to enhance productivity.
Coolant tank with 100 Ltr. capacity and powered with electric coolant pump.
Adjustable tungsten carbide face blade guides with ball bearings at either side of cutting bar
Hydraulically operated main vice with double acting full stroke cylinder
"Hydraulically controlled automatic feed regulation through a state of the art sensor to Optimize
production and tool life."
"High pressure coolant jets through blade guide helps coolant to enter in to the bar through blade
gullets to optimize productivity and tool life."
"Automatic blade guide setting with the opening and closing of moving vice to avoid accident due
to negligence of the operator. Also, moving blade guide always remains very close to the bar."
"Cutting feed through infinitiely variable flow control valve with cutting pressure regulation, as per
the material property."
"Heavy duty Warm reduction gear box for blade rotation to minimize polygon effect to enhance
tool life, surface finish and minimize vibration during cutting."
"Heavy duty energy efficient electric motor directly coupled to the gear box to minimize belt
slippage losses."
Control panel with necessary switch gear and step down transformer for control circuit
"Split vice:- Machine is designed to offer burr free cutting with the help of split vice were in raw
material bar and cut piece are clamped rigidly till the cutting head goes up after cutting which
also avoid rubbing of blade."
"To optimize productivity and blade life, constant beam strength is obtained through a
contentiously monitored stretching of blade through a hydraulically operated blade tension
Linear motion guide rail & bearings on vertical columns are lubricated through oil pump.
"Hydraulic power pack with sufficient oil tank capacity and necessary control elements is provided
on the machine."
Cutting feed and rapid reverse of cutting arm.
"Blade Tensioning when hydraulic power is on and tension release no sooner machine is off to
minimize fatigue stresses."
Auto stop of machine when blade breaks.
Blade guards for operator safety near clamping area.
"Machine is designed to feed material for cutting from either side as per the convenience of the
Floating Shuttle Vice mounted on four Heavy duty linear bearing block for self alignment depending upon work piece straightness or surface roughness. Bar stock slideson main vice without any resistance as shuttle vice adjusts automatically.
Auto cycle sequencing with PLC.
Piece counter & length multiplier through PLC.
Electrically driven Swarf Conveyor with Container.
Hand operated lubrication system for main columns bearings.
Electrical control panel with push button, emergency stop button, main isolater, PLC, VFD, step down transformer, auxiliary contractor, cable connector and connector with fuses with fuses for solenoid coil to protect PLC.
Motorized rotating cleaning wire brush
